Main Features:

‌Fuel Economy‌: The 4G15S engine is equipped with Delphi's next-generation electronic fuel injection management

 system MT0U2, adopting the MVV vertical vortex lean combustion technology. It has a fuel consumption of only

4.7L per 100 km, good fuel economy‌. ‌

Power Performance‌: This engine can output a maximum power of 76kW at 600 rpm and a maximum torque of

130N·m at 4500 rpm, demonstrating strong power performance‌.

Technical Improvement‌: The 4G15S is an improved version of the 4G18, with many interchangeable parts between

the two engines The crankshaft rotation angle of the 4G15S is larger than that of the 4G18, allowing it to complete

 more power strokes in same time‌.

Applicable Vehicle Models:

The 4G15S engine is suitable for a variety of models, including light commercial vans, economy sedans, and SUV Specifically,

the 4G15S engine has a wide range of applications, mainly used in light commercial vans. For example, Great Wall Motor

extensively uses 4G15S engine in its Haval series of SUVs, which performs excellently in terms of power smoothness and

low maintenance costs, earning trust and praise of consumers.

Main Parameters:

Number of cylinders:

Fuel type: Gasoline

Displacement: 1.488L

Maximum power output: 76kW (109 HP)

Maximum torque: 130N·m

Maximum torque RPM: 500rpm

Compression ratio: 10:1

Bore x stroke: 76×82mm
